GUARD TEMP™ Digital Temperature Gauge (DTG)

Product Details

(Click to enlarge image) The GUARD TEMPTM Digital Temperature Gauge (DTG) is a fully digital tank temperature sensor designed for tank ships and tank barges that significantly saves on deck cabling, IS barriers and I/O cost.

The simple 2-wire connection from the cargo tank to main control panel for all three measurement points is one advantage that makes this possible. Also adding value, GUARD TEMP DTG has three digital temperature sensors (daisy chained) per cargo tank. These digital temperature sensors connect to a sensor collection unit (SCU) with an optional LCD for local display.

The unit is certified Intrinsically Safe and is typically fitted into shipyard provided thermowell or a FRAMO style deep well pump. Multiple mounting options are available and with a one-inch minimum thermowell size. And, it can connect directly to CARGORADAR® or separately run to CCR with our 2-core cable.
